Grade: LTG476. (Type: Glass Fibre – SRBG).
Description: Epoxy Glass.
Comments: A high quality epoxy glass tube which is suitable for use at 155°c (class F). Material exhibits high mechanical and electrical strength, low water absorption, high resistance to chemicals and high insulation resistance. An excellent all round performance.
Specifications: IEC/EN61212-3-1: EP GC 22. DIN7735: HGW 2375.4. NEMA equivalent: G-11.
Grade: LTG475. (Type: Glass Fibre – SRBG).
Description: Epoxy Glass.
Comments: As LTG476 but utilises a fine-weave glass cloth for improved machining capabilities. Predominantly used for tubes with an ID of less than 10mm.
Specifications: IEC/EN61212-3-1: EP GC 22. DIN7735: HGW 2375.4. NEMA equivalent: G-11.
Grade: LTG474. (Type: Glass Fibre – SRBG).
Description: Epoxy Glass. Flame Retardent.
Comments: A high quality epoxy glass tube which is suitable for use at 130°c (class B). The material offers mechanical and electrical properties similar to those of LTG472, but with the addition of flame retardant properties.
Specifications: IEC/EN61212-3-1: EP GC 23. NEMA equivalent: FR-4.
Grade: LTG473. (Type: Glass Fibre – SRBG).
Description: Epoxy Glass. Flame Retardent.
Comments: As LTG474 but utilises a fine-weave glass cloth for improved machining capabilities. Predominantly used for tubes with an ID of less than 10mm.
Specifications: IEC/EN61212-3-1: EP GC 23. NEMA equivalent: FR-4.
Grade: LTG472. (Type: Glass Fibre – SRBG).
Description: Epoxy Glass.
Comments: A general purpose, mechanical grade tube which is suitable for use at 130°c (class B). The material offers particularly good electrical and mechanical properties and a high resistance to chemicals.
Specifications: IEC/EN61212-3-1: EP GC 21. DIN7735: HGW 2375. NEMA equivalent: G-10.
Grade: LTG480. (Type: Glass Fibre – SRBG).
Description: Silicone Glass.
Comments: High quality silicone glass tube which is suitable for use at 220°c (class H). The material exhibits excellent electrical properties, low water absorption, and low dielectric loss factors in both high temperature and high frequency applications.
Specifications: IEC/EN61212-3-1: SI GC 21. DIN7735: HGW 2575. NEMA equivalent: G-7.
Grade: LTG479. (Type: Glass Fibre – SRBG).
Description: Silicone Glass.
Comments: As LTG480 but utilises a fine-weave glass cloth for improved machining capabilities. Predominantly used for tubes with an ID of less than 10mm.
Specifications: IEC/EN61212-3-1: SI GC 21. DIN7735: HGW 2575. NEMA equivalent: G-7.
Grade: LTG487. (Type: Glass Fibre – SRBG).
Description: Silicone Glass.
Comments: Similar to LTG480 material, but LTG487 possesses a high deformation temperature performance (350oC). This material is widely used as nozzle insulators in wire welding guns where a shielding gas is used.
Specifications: IEC/EN61212-3-1: SI GC 21. DIN7735: HGW 2575. NEMA equivalent: G-7.
Grade: LTG490. (Type: Glass Fibre – SRBG).
Description: Melamine Glass.
Comments: A high quality melamine glass tube which is suitable for use at 130°c (class B). The material offers high arc and track resistance and is widely used in applications which require consistent insulation from high electrical voltage.
Specifications: IEC/EN61212-3-1: SI GC 21. DIN7735: HGW 2575. NEMA equivalent: G-7.
Grade: LTP405. (Type: Phenolic Paper – SRBP).
Description: Commercial Grade Phenolic Paper.
Comments: A high quality commercial grade phenolic paper tube. The material possesses high mechanical strength and machining properties. Good electrical properties at normal air humidity.
Specifications: IEC/EN61212-3-1: PF CP 21. DIN7735: HP2065. NEMA XX.
Grade: LTP400. (Type: Phenolic Paper – SRBP).
Description: Superior Grade Phenolic Paper.
Comments: A superior grade of phenolic paper tubing to LTP405. The material exhibits higher electrical properties and lower water absorption to that of LTP405, whilst also possessing high mechanical strength and machining properties.
Specifications: IEC/EN61212-3-1: PF CP 23. DIN7735: HP2067. NEMA equivalent: XXX.
Grade: LT21. (Type: Phenolic Paper – SRBP).
Description: Special Grade Phenolic Paper.
Comments: Specially developed material for mechanical applications, LT21 material has excellent hoop strength and superb machining properties. LT21 material is used to make the Lantex® Spin Bobbins, which are supplied worldwide.
Grade: LTC452. (Type: Phenolic Cotton – SRBF).
Description: Commercial Grade Phenolic Cotton.
Comments: Our standard grade of phenolic cotton tubes, LTC452 material possesses excellent mechanical strength and good impact resistance. LTC452 exhibits good electrical properties, machining properties, and can be lubricated with water, oil, or grease.
Specifications: IEC/EN61212-3-1: PF CC 22. DIN7735: HGW 2085. NEMA equivalent: CE.
Grade: LTC455. (Type: Phenolic Cotton – SRBF).
Description: Superior Grade Phenolic Cotton.
Comments: A superior grade of phenolic cotton tube to LTC452. The material exhibits higher electrical properties to that of LTC452 and is reinforced with a finer cotton base substrate, ideal for intricate machining and a smoother finish.
Specifications: IEC/EN61212-3-1: PF CC 21. DIN7735: HGW 2086. NEMA equivalent: LE.
Grade: FT19M (Type: Silicone Bonded Muscovite Mica).
Comments: Our most popular grade of mica tube, FT19M is composed of muscovite mica bonded with silicone resin. The material possesses excellent electrical and thermal properties, and is used in a wide variety of applications. FT19M material does not support combustion and can withstand a constant temperature of 650°c.
Specifications: BSEN 61212-3-1:SIMP21.
Grade: FT19P (Type: Silicone Bonded Phlogopite Mica).
Comments: Our FT19P tubes are composed of silicone bonded phlogopite mica, which allows the tubes to withstand higher operating temperatures to those of the FT19M grade. Similar in appearance with a smooth finish, our FT19P tubes are widely used in bolt insulation assemblies used in high temperature applications.
Specifications: BSEN 61212-3-1:SIMP21.
Grade: FT75M (Type: Epoxy Bonded Phlogopite Mica).
Comments: Our FT75M tubes combine muscovite mica with an epoxy resin system, to further complement our versatile range of Filamic® mica tubes. Although the FT75M material has a lower temperature rating than the FT19 range of tubing, it is characterised by excellent mechanical and electrical strength, along with low water absorption.
Specifications: BSEN 61212-3-1:EPMP21.
